Fiber Laser Tube Cutting Machine | Han’s Laser | RiseTek Machinery Canada

Han’s Laser · Authorized Canadian Distributor

Fiber Laser Tube
Cutting Machine

Precision fiber laser cutting for round, square, oval, and profile tubes. Powered by Han’s Laser — available across Canada through RiseTek Machinery.

Explore MachinesRequest a Quote
Max Tube DiameterØ660mm
Max Load Capacity2,500 kg
Tube LengthUp to 12m

Machinery by Han’s Laser Smart Equipment Group · ISO 9001 & ISO 14001 Certified · Since 1996

Han’s Laser · Fiber Laser Tube Cutting Series

Choose Your Series

Two industrial platforms built for different tube cutting demands.

TX Series
Heavy-Duty
Tri / Four-Chuck

TX Series

Heavy-Duty Fiber Laser Tube Cutting Machine

Max Tube DiameterØ660mm
Max Load Capacity2,500 kg
Max Tube LengthUp to 12m
Max Speed60 m/min

The TX Series is Han’s Laser’s heavy-duty fiber laser tube cutting platform — built for large-diameter round and square tubes up to 660mm and 2,500kg. Side-mounted bed, follower-assisted support, and true zero-scrap cutting. Available in tri-chuck and four-chuck configurations with optional ±45° bevel cutting.

  • True zero scrap — cutting head crosses center chuck
  • Side-mounted bed: strong rigidity, long-term precision
  • Follower-assisted floating support prevents tube sagging
  • Tri-chuck and four-chuck configurations
  • Optional ±45° bevel cutting
  • Semi-automatic loading and unloading
  • Bus control technology for fast response
Learn MoreRequest a Quote
PD Series
Small & Medium Tube
2-Chuck · Pneumatic 4-Claw

PD Series

Expert for Small & Medium Size Tube · P6010D / P6018D / P8018D / P10018D

Machining RangeØ20–180mm
Max Load Capacity260 kg
Max Material Length12,200mm
X/Y Rapid Traverse120 m/min

The PD Series is Han’s Laser’s dedicated fiber laser cutting machine for small and medium tubes — modular design, four models (P6010D–P10018D), 1–4kW laser power. Fully enclosed dustproof chuck, pneumatic four-claw self-centering, digital clamping monitoring, and servo floating support for continuous 24-hour production.

  • Fully enclosed dustproof claw — pneumatic 4-claw self-centering
  • Mechanical transmission chuck — internal oil circulation, 24-hour operation
  • Digital clamping monitoring — real-time pipe size identification
  • Rear chuck with exhaust — removes gas, prevents thermal deformation
  • Servo floating support — prevents pipe sagging
  • Adjustable console — multi-angle rotation
  • Semi-automatic and fully-automatic feeding options
Learn MoreRequest a Quote

Side by Side

Which tube laser is right for you?

Specification
TX Series
PD Series
Category
Heavy-Duty · Large Diameter
Expert · Small & Medium
Max Round Tube
Ø40–660mm
Ø20–180mm
Max Tube Length
Up to 12,000mm
Up to 12,200mm
Max Load
2,500 kg
260 kg
Rapid Traverse
60 m/min
120 m/min
Chuck System
Tri / Four-chuck
2-chuck pneumatic 4-claw
Bevel Cutting
✓ ±45°
– Straight only
Automation
Semi-auto
Semi + fully-auto
Best For
Structural steel, shipbuilding, heavy profiles
Furniture, fitness, automotive, HVAC

Technical Data — TX Series

TX Series · Three Models

All data subject to actual technical documents.

SpecificationTX12036TTX12050TPX12066F
Processing (Round)Ø40–360mmØ50–500mmØ80–660mm
Processing (Square)□40–350mm□50–500mm□80–450mm
Positioning Accuracy±0.05mm/1000mm±0.05mm/1000mm±0.01mm/1000mm
Max Speed60 m/min60 m/min40 m/min
Processing Length0–12,000mm5,800–12,100mm0–12,000mm
Leftover Materials≥0 (Zero Scrap)≥0 (Zero Scrap)≥0 (Zero Scrap)
Max Tube Weight1,200 kg2,000 kg2,500 kg

Full data sheet available upon request

Technical Data — PD Series

PD Series · Four Models

For reference only — all data subject to actual technical documents.

SpecificationP6010D / P6018D / P8018D / P10018D
Laser Power1–4kW (Customizable)
Machining RangeΦ20–180mm (Opt: Φ20–110mm)
Rapid Traverse120 m/min
Max Load260 kg
Max Length12,200mm
ChuckPneumatic 4-claw self-centering · Dustproof
FeedingSemi-auto / Fully-auto (optional)

Full data sheet available upon request

Compatibility

Cuts any tube, any profile.

Carbon Steel
Round, square, oval
Stainless Steel
Precision grade
Aluminum Alloy
All tempers
Special Profiles
H-beam, angle, channel

Why Han’s Laser

Built for tube production.

🔄
True Zero Scrap

TX Series cutting head crosses center chuck — eliminating end-piece waste entirely.

🎯
Precision Chucks

Full-stroke chuck systems eliminate jaw changes when switching tube sizes.

🏗️
Heavy Load

TX Series handles tubes up to 2,500kg with rigid side-mounted bed.

📐
Bevel Cutting

Optional ±45° bevel with Han’s proprietary groove cutting head.

🤖
Automation

Semi-auto feeding standard. PD Series also supports fully-automatic bundle loading.

🇨🇦
Canadian Support

RiseTek provides local sales, installation, training, and aftermarket support.

Applications

Engineered for your industry.

🏗️
Structural Steel
H-beams, columns, braces for construction.
🚗
Automotive
Chassis, roll cages, exhaust systems.
🚢
Shipbuilding
Large-diameter pipes and frame members.
🏭
Heavy Fabrication
Equipment frames, crane components.
🏠
HVAC
Ductwork, fittings, mechanical systems.
🔩
Furniture
Tubular frames, railings, decorative metal.
🌱
Agriculture
Greenhouse structures, irrigation pipe.
🔋
New Energy
Solar mounting, wind turbine components.

Available in Canada

Local support.
Canadian service.

RiseTek Machinery — authorized Canadian Han’s Laser distributor, Mississauga, Ontario.

🇨🇦
Authorized Distributor
Factory-level support, genuine parts, certified technicians.
🔧
Local Parts & Service
Canadian parts inventory for fast turnaround on repairs and service.
✅
CSA Certification
Meets CSA electrical safety standards for Canadian workplaces.

RiseTek Machinery · Han’s Laser · Canada

Ready to cut tube smarter?

Talk to our tube laser specialists and find the right TX or PD Series for your requirements.
