Spindle Moulder with Front Carriage TC 120
| Fixed worktop dimensions | mm 640×1100 |
| Aluminum Carriage Dimensions | mm 360×1100 |
| Available shaft diameters | mm 30-35-40-50 |
| Max. opening size on the table | 350×80 mm |
| Shaft vertical stroke (Ø 30-35) | mm 140 |
| Vertical shaft stroke (Ø 40-50) | mm180 |
| Worktop height | mm 890 |
| Shaft speed | rpm 2500/4200/6000/8000/10000 |
| Motor power | HP 5.5 |
| Machine weight | kg 640 |
- Spindle moulder cap
- Guide with protractor
- Eccentric Presser
- 2 extractor hoods ( 1 x ø 80 mm, 1 x ø 120 mm)
- Manual star-delta starter
- Spindle moulder cap
- Spindle moulder guide with linear movement by means of handwheels and movements displayed by mechanical decimal numerators.
- Sliding on recirculating ball linear guides.
- Guide with protractor
- Eccentric Presser
- 2 extractor hoods ( 1 x ø 80 mm, 1 x ø 120 mm)
- CE type profile protection
- Contour CE type protection
- Automatic delta star start
- Self-braking motor
- Electric predisposition for driver
- Numerical display for lifting the mast
- LED speed display with light diodes
- CE type protections
ACCESSORIES ON REQUEST
45° tilting spindle moulder with electronic digital angle reading display
Version with sliding carriage in aluminium length 2250 mm
Spindle moulder guide with linear movement by means of handwheels and movements displayed by mechanical decimal numerators. Sliding on recirculating ball linear guides. (standard version)
7.5 HP motor
10 HP Motor
Engine HP 12
Surcharge for self-braking motor with brake release (standard version)
Motor protection and emergency mushroom (standard version)
Rotation reversal (standard version)
Rotation reversal (CE version)
Electronic digital display shaft height
Digital mechanical shaft height display (standard version)
Light-emitting diode speed display (standard version)
Tenonare table (only available for standard version)
Tenonare cap
Tenoning table and tenoning cap
Added top front with flag
Sheet metal side extension surfaces (total length 2200 mm)
Spindle moulder shaft with slot (only available for standard version)
MK4 interchangeable shaft
Extra top shaft for MK4
Aluminum guide for “lamellar” type boot
Aluminum rail for headset
CE type profile moulder protection (standard version)
TAPOA type moulding shaft protection (standard version)
Spindle moulder hood exclusion by means of a folding support
Console control panel
Hanging control panel
Motorized mast lifting with electronic positioner
Motorized shaft tilt with electronic positioner
Mast lifting and tilting with movements managed by the VK3 control panel with manual and automatic function and the possibility of incremental movements
Shaft speed managed by inverter
